DVI to VGA Converter
Model No：VC-100DV
VC-100DV is a high-performance single-chip DVI/HDMI to VGA converter，combined with DVI 1.0 receiver and triple DACs, this converter supports DVI input and VGA output by conversion functi。It can help NBs、Ultrabooks and tablets to be compatible with traditional VGA only projectors, monitors, and TVs
- Features & Spec.
- Diagram
- PDF
Features
- Fully compliant with HDMI 1.3a specification. With HDMI 1.3a receiver, can support resolutions up to Full HD ( 1080P ), WUXGA and UXGA. Also the build-in triple DACs can support up to 10 bit deep colors
- Supporting link speeds of up to 2.25Gbps (link clock rate of 225MHz)
- Auto-calibrated input termination impedance provides process-, voltage- and temperature-invariant matching to the input transmission lines
- ( VGA DACs) / Tripe 10-Bit DAC Converters / 200 MSPS Throughput Rate / Complementary Outputs / DAC Output Current Range 2mA to 18.5mA
- Supports Full HD ( 1080P ) CEA display format, WUXGA(1920X1200 RB mode) and UXGA (1600x1200) VESA display format
- HDMI Input deep color depth up to 12bit, and support VGA output deep color depth up to 10bit / Embedded MCU and Flash / RoHS Compliant ( 100% Green available )
- Compable DVI port of PC / MAC / PS3 / DVD Player / HD Media Player……...
- Easy to install , Plug & Play, Powers free (With 5V power Plug - for No power of DVI Interface)
- With screw hall / easy fasten
- Connector : DVI-M 15CM Cable + BODY & VGA-F
Specifications
| Model no. |
VC-100DV
|
| Input Connector |
1*DVI-D ( 18+1 ) Male
|
| Out Connector | 1*HDB-15 Female |
| Resolutions | 1080p, 1440*900, 1600*1200(UXGA), 1920*1200(WUXGA) |
| Working Temperature | 5 ~40°C |
| Power Source | None Power |
| Size | 54*46*15mm |
| Weight | 45g |
