RS422/485 Repeater

型號：RE285
RPE285 是設計來增益 RS422/485 的訊號，使用簡單不需要安裝軟體。只需設定 DIP switch 就可切換 RS422 或 RS485。此外，此產品是完全相容主機上的 serial COM 埠
  • 產品介紹
  • 產品應用圖

產品功能

  • Fully compatible with serial RS422/485
  • DC power supply (10~30V) Built in Surge Protector
  • Auto Toggling by hardware
  • Communication status can be monitored through LEDs
  • Dip switch for selecting RS422/485 modes, Terminal Resistance
  • Max. 10 Device Connectivity for RS422 Multi-Drop Mode
  • Max. 32 Device Connectivity for RS485 Mode
  •  可應用於下列環境:
    RS-422/485 communication，Utility meters，Industrial process control，Building automation，Industrial-controlled Local Area Network，Industrial PCs and PC peripherals devices

產品規格
